◾Applicable to automatic winding for air coil.
◾This model with 2-axes independent AC servo motor applied to drive
flyers and wire spreading core for high speed accurate and precise coil
winding.
◾Modular molds and dies design, it is able to make fast positioning,
and with high repetitive precision, to reduce time required for mold die
changes tremendously.
◾Dies can be shared for this series, reduces the cost of mold
development tremendously.
◾The analog tension output control system provides tension for different
coil winding stages and increases quality level of product.
◾Based on Japanese PLC controller with touch panel promptly to
display various operation statuses and running monitoring function.
◾It is able to equip with remote monitoring module to do remote
program monitoring safeguard.
＊Please contact TeamWork for requirements outside these specifications.
We reserve the right of technical modifications without notice.
